PRODUCT INFORMATION

Operating Voltage： 8V~25V

Operating Current：52mA

Operating Temperature：-20°C~70°C(-4F~158F)

Storage Temperature：-30°C~80°C(-22F~176°F)

LCD Screen：2.4′ TFT color screen

Dimensions：(L)132mm x(W)85mm x(H)22mm

Support datastream type：249

Fault codeanalysis number:16929

Function Description

(1) Dual-system diagnostic, optional engine andtransmission.

(2) Quickly indicate engine faults, with green / yellow / red LED indicators as fault lights.

(3) To read or clear engine fault codes, 16929 diagnostic trouble code definitions can be inquired.

(4) Dynamic display of sensor data stream information,supporting 249 types of sensors.

(5) View freeze frame data and I/M status information.

(6) Read vehicle information: vehicle identification number(VIN), calibration identification number(lDs)calibrationverification number(CVNs).

(7) Test cranking and charging system of the vehicle.

(8) Multi-language：German, English, Spanish, French, Italian, Dutch, Polish, Finnish
